Features:
◆ Design of positive pressure type helps the corrugated board to be pressed evenly on the corrugated rolls and applied with the glue, which could make the board pasting much better.
◆ Rapid change of the rolls in 15mins. Electrical trolleys are used for output and input of the corrugated rolls. Easily and rapidly.
◆ The corrugated rolls and pressure roll are using the airbag control system which is steadier during running.
◆ The amount and applying width of the glue is motorized controlled. The gluing system can operate independently during the pause of the plant which could avoid being dried.
◆ The movable gluing system is convenient for cleaning and maintaining.
◆ Touch screen interface with digital status display, simple to operate and control.
◆ Inner spraying system which could adjust the temperature and moisture of the liner.
◆ Because of the cassette design, it is very easy to change the corrugated rolls with different flute type and saves the investment and daily cost.
Specifications:
| Model | SF-405E | SF-360E | SF-320E |
| Design Speed (m/min) | 250 | 200 | 180 |
| Effective Width (mm) | 1400-2500 | ||
| Dia. of Corrugated Roll (mm) | 405 | 360 | 320 |
