Features:
◆ Memory of 999 orders, auto or manual of changing the order without stopping machine.
◆ Servo motor control for all the slitting and scoring blades, rapid and accurate movement.
◆Double lines of the creasing wheels which could achieve zero creasing gap.
◆ Auto speed tracking of the plant speed which ensures the synchronization. Can connect with the production management system. High compatibility.
◆ Control system is composed by the imported high quality industry computer and PLC with high performance.
◆ Can achieve three different types of the creasing lines: male-female, male-male and male-flat. All are motorized changed. Depth of the creasing is controlled by the computer, good forming and easy for folding.
◆ Adopting tungsten blade, sharp and long life (over 8million meters)
◆ Auto or manual for blade grinding. Can slitting and grinding at same time, increasing the efficiency of the plant.
◆ Imported timing belt, higher precision, longer life and less noise.
◆ Equipped with strippers. According to the blades, their position are automatically adjusted during the order change.
Specifications:
| Model | NCBD-200 | NCBD-250 |
| Design Speed (m/min) | 200 | 250 |
| Effective Width (mm) | 1800-2500 | |
