Main Features
1.Heightened top sheet feeding table can load more bottom sheets and increase the efficiency.
2.Turn-up bridge plate is convenient for cleaning and discontinuous water-circulating system for the cleaning.
3.Automatic feeding of the bottom sheet, manual feeding for the top sheet convenient and accurate.
4.Flexible front registration. The bottom sheet is not exceeding the top sheet, and the gap between them is adjustable.
5.Suitable for the lamination of the paperboard with A/C/B/E/F flute corrugated cardboard and cardboard with cardboard (top sheet shall be larger than 350gsm).
6.Intelligent control for the pressing, energy saving, the distance of the stacking is adjustable.
7.Using high-precision plastic block device, glue saving.
8.Optional:
a)Side feeding of the top sheet;
b)PLC control;
c)Enlarge the compression part;
d)Lifting platform of the top sheet.
Specifications:
| Model | FMB-1300 | FMB-1450 | FMB-1650 |
| Max. Sheet Size (mm) | 1300*1100 | 1450*1100 | 1650*1300 |
| Min. Sheet Size (mm) | 350*400 | ||
| Power | 8.5 | 8.5 | 10 |
| Max. Speed (pcs/min) | 0-90m/min | ||
| Machine Weight (KG) | 3200 | 3400 | 3600 |
| Overall Dimensions (mm) | 9000*2020*1900 | 9000*2170*1900 | 9000*2370*1900 |
