Main Features
1.One minute for changing the size.
2.Easy and convenient for the operation, no requirements of working experience for the operators.
3.Can stitch single (/), double (//) and tie (// / / //) at the same time, meeting with different requirements.
4.Auto counting and output at the stacking unit for the bundling.
5.Operated by the touch screen.
6.Double Servo motors of Yaskawa, Japan.
7.Can stitch the box with cover or without cover, distance can be set in the touch screen along with the thickness of the board.
Specifications:
| Model | BZD-2800 |
| Max. Speed (nails/min) | 600 |
| Nail Distance (mm) | 30-120 |
| Nail size (mm) | No. 17 & 18 |
| Max. Feeding size (mm) | 2800*1510 |
| Min. Feeding Size (mm) | 680*300 |
| Feeding Height (mm) | 900 |
